SS8-54HSB 390~410M All Black

Solarspace Technology Co., Ltd
タイプ: PERC
出力領域: 390 ~ 410 Wp
地域: 中国 中国
注意:お問い合わせはSolarspace Technology Co., Ltd.に直接に送信されます。


  • High-performance solar module series that can generate up to 410W of power at 21% efficiency

  • Our modules employ advanced technologies like the PERC, half-cut, and multi-busbar designs

  • Gallium-doped silicon cells protect the module from light-induced degradation

  • Designed to withstand harsh weather conditions


SS8-54HSB 390M SS8-54HSB 395M SS8-54HSB 400M SS8-54HSB 405M SS8-54HSB 410M
製品保証 12 年
390 Wp 395 Wp 400 Wp 405 Wp 410 Wp
30.64 V 30.84 V 31.01 V 31.21 V 31.45 V
12.73 A 12.81 A 12.9 A 12.98 A 13.04 A
36.85 V 36.98 V 37.07 V 37.23 V 37.32 V
13.61 A 13.7 A 13.79 A 13.87 A 13.95 A
19.98 % 20.23 % 20.48 % 20.74 % 21 %
出力誤差 (+)
+ 1.5 % + 1.5 % + 1.5 % + 1 % + 1 %
  JIS規定検査条件(AM 1.5, 放射照度 1000W/m2, モジュール温度 25°C)
294 Wp 298 Wp 302 Wp 306 Wp 310 Wp
28.87 V 29.08 V 29.26 V 29.47 V 29.72 V
10.18 A 10.25 A 10.32 A 10.38 A 10.43 A
34.62 V 34.75 V 34.88 V 35.12 V 35.23 V
10.89 A 10.96 A 11.03 A 11.1 A 11.16 A
最大耐久温度 45±2 °C
  公称動作条件(放射照度800W/m2, AM 1.5, 風速1m/s,ambient temperature 20°C)
作動温度範囲 40~85 °C
温度係数(Pmax) 0.35 %/°C
温度係数(Voc) 0.275 %/°C
温度係数(Isc) 0.045 %/°C
最大入力電圧 1500 V
定格入力電流 25 A
外形寸法 (高さ/幅/奥行) 1722x1134x30 mm
質量 22 kg
セルタイプ PERC
セルサイズ 182x182 mm
1枚当たりのセル数 108
バイパスダイオード数 3
ジャンクションボックス保護 IP 68
ケーブル断面 4 mm2
