OS-HP72-330-350W

Hebei Oushang Photovoltaic Technology Co., Ltd.
価格:
価格 ¥36.3 / Wp より
タイプ: 多結晶
出力領域: 330 ~ 350 Wp
地域: 中国 中国
注意:お問い合わせはHebei Oushang Photovoltaic Technology Co., Ltd..に直接に送信されます。

説明:

MONO 72 CELLS, 5BB

High power output, High transmission glass

PID Resistant

By pass Diodes protection

TUV, CE, ISO9001, SGS

製品の特徴

型式
OS-HP72-330 OS-HP72-340 OS-HP72-350
保証制度
製品保証 10 年
規定検査条件化での性能
最大出力(Pmax)
330 Wp 340 Wp 350 Wp
最大出力作動電圧(Vmpp)
37.64 V 38.02 V 38.35 V
最大出力作動電流(Impp)
8.77 A 8.94 A 9.13 A
開放電圧(Voc)
45.38 V 45.82 V 46.17 V
短絡電流(Isc)
9.24 A 9.44 A 9.6 A
出力誤差 (+)
+ 3 % + 3 % + 3 %
出力誤差 (-)
- 3 % - 3 % - 3 %
  JIS規定検査条件(AM 1.5, 放射照度 1000W/m2, モジュール温度 25°C)
公称動作環境での性能
最大耐久温度 47±2 °C
  公称動作条件(放射照度800W/m2, AM 1.5, 風速1m/s,ambient temperature 20°C)
温度特性
作動温度範囲 40~85 °C
温度係数(Pmax) 0.45 %/°C
温度係数(Voc) 0.35 %/°C
温度係数(Isc) 0.05 %/°C
システム統合パラメータ
最大入力電圧 1500 V
その他仕様情報
外形寸法 (高さ/幅/奥行) 2015x996x35 mm
セルタイプ 多結晶
1枚当たりのセル数 144
ガラスタイプ 強化ガラス
保護剤 EVA
バックカバー TPT
構造フレームタイプ 陽極酸化アルミニウム合金
ジャンクションボックス保護 IP 67
コネクター MC4
ケーブル断面 4 mm2
PDF
メーカーのPDFをダウンロードします
