STM-440-465/144-S2 2120*1052*35

Anhui Schutten Solar Energy Co., Ltd.
技術:
出力領域: 440 ~ 465 Wp
地域: 中国 中国
メーカーに連絡する
注意:お問い合わせはAnhui Schutten Solar Energy Co., Ltd..に直接に送信されます。

説明:

● High efficiency, durability and weather resistance

● 144 half-cut monocrystalline cells that provide efficiency of up to 20.8%

● Anodized aluminium frame, high transmittance tempered glass and an IP67 protected junction box

● Able to withstand mechanical stress loads up to 5400 Pascal of front load and 2400 Pascal of back load

● 12-year manufacturer warranty

製品の特徴

タイプ 単結晶
型式
STM-440/144-S2 STM-445/144-S2 STM-450/144-S2 STM-455/144-S2 STM-460/144-S2 STM-465/144-S2
保証制度
製品保証 12 年
出力保証 84.8%の出力を25年間保証
規定検査条件化での性能
最大出力(Pmax)
440 Wp 445 Wp 450 Wp 455 Wp 460 Wp 465 Wp
最大出力作動電圧(Vmpp)
40.9 V 41.21 V 41.52 V 41.82 V 42.13 V 42.43 V
最大出力作動電流(Impp)
10.76 A 10.8 A 10.84 A 10.88 A 10.92 A 10.96 A
開放電圧(Voc)
49.4 V 49.56 V 49.7 V 49.85 V 50.01 V 50.15 V
短絡電流(Isc)
11.28 A 11.32 A 11.36 A 11.41 A 11.45 A 11.49 A
モジュール変換効率
19.7 % 20 % 20.2 % 20.4 % 20.6 % 20.8 %
  JIS規定検査条件(AM 1.5, 放射照度 1000W/m2, モジュール温度 25°C)
公称動作環境での性能
最大出力(Pmax)
333 Wp 336 Wp 340 Wp 344 Wp 348 Wp 352 Wp
最大出力作動電圧(Vmpp)
38.7 V 38.95 V 39.19 V 39.44 V 39.68 V 39.9 V
最大出力作動電流(Impp)
8.6 A 8.64 A 8.68 A 8.72 A 8.76 A 8.81 A
開放電圧(Voc)
46.4 V 46.65 V 46.9 V 47.15 V 47.38 V 47.61 V
短絡電流(Isc)
9.16 A 9.2 A 9.25 A 9.29 A 9.33 A 9.38 A
最大耐久温度 45±2 °C
  公称動作条件(放射照度800W/m2, AM 1.5, 風速1m/s,ambient temperature 20°C)
温度特性
作動温度範囲 -40~85 °C
温度係数(Pmax) -0.35 %/°C
温度係数(Voc) -0.272 %/°C
温度係数(Isc) 0.044 %/°C
システム統合パラメータ
最大入力電圧 1500 V
定格入力電流 20 A
その他仕様情報
外形寸法 (高さ/幅/奥行) 2120x1052x35 mm
質量 25 kg
1枚当たりのセル数 144
バイパスダイオード数 3
ジャンクションボックス保護 IP 67
コネクター MC4
ケーブル断面 4 mm2
ケーブルの長さ 300 mm
PDF
メーカーのPDFをダウンロードします

Certification

Our products have been approved by international certifications like TUV, CE, IEC, INMETRO, BIS, etc., and domestic certifications like CQC, ISO9001, ISO14001, OHSAS18001, etc.

STM-440-465/144-S2

First-class solar panel warranty

12-year Warranty for Materials and Processing

25-year Warranty for Extra Linear Power Output

Supplier

Product Characteristics

High efficiency, durability and weather resistance.

144 half-cut monocrystalline cells that provide efficiency of up to 20.8%.

Anodized aluminium frame, high transmittance tempered glass and an IP67 protected junction box.

Able to withstand mechanical stress loads up to 5400 Pascal of frontload and 2400 Pascal of backload.

12-year manufacturer warranty.

About Schutten

Schutten Solar is a world leading solar module manufacturer and comprehensive solar solution provider. We are specialized in highly efficient solar module research, manufacturing and distribution to global market with advanced module production capacity available both in China and abroad. Schutten is located in Chuzhou city, Anhui province, China since 2013. Till now, we accumulatively shipped above 10GW solar modules to more than 100 countries, developed and built 500MW solar projects all over the world.

Anhui Schutten Solar Energy Co., Ltd.

Click to show company phone
www.schutten-solar.com
中国
No.888 Weisan Road, Economic Development Zone, Quanjiao County, Chuzhou, Anhui
スタッフナンバ―: 1,000
注意:お問い合わせはAnhui Schutten Solar Energy Co., Ltd..に直接に送信されます。

結晶系

生産高 (MW)/: MWp
単結晶
パワーレンジ(Wp): 180-675
企業説明

Anhui Schutten Solar Energy Co., Ltd., founded in 2013, is a national high-tech enterprise integrating advanced technology and innovative capabilities. We specialize in the R&D, production, and sales of photovoltaic products, providing solutions and services for photovoltaic power stations and systems.

The company has a strong R&D team and has established a comprehensive cooperation relationship with the Chinese Academy of Sciences and universities. We also collaborate with many industry-leading enterprises and institutions both domestically and internationally. Our innovative approach has resulted in numerous patented technologies, earning us a significant position in the industry.

Our state-of-the-art photovoltaic production line ensures high-quality products. We have established a production capacity of 3GW and our product lineup includes PERC, TOPCon, and other high-efficiency photovoltaic modules. Our products have passed multiple international certifications including TUV, CE, CGC, BIS, INMETRO, and others. We have exported to more than 100 countries and regions.

We are committed to continuous innovation and improvement, striving to provide the best products and services to our customers, contributing to the global green energy transition.
